ASRock K7S41GX Rev 1.02 Mainboard + Blende
Sockel A 462 FSB333 DDR AGP PCI
Technische Daten
CPU
- Socket 462, supporting AMD Sempron, Athlon, Athlon XP, Duron
- FSB 333/266/200 MHz
Chipset
- Northbridge: SiS 741GX
- Southbridge: SiS 963L
Memory
- 2 x DDR DIMM
- DDR333/266 non-ECC, un-buffered memory
- Max. capacity of system memory: 2GB
BIOS
- 2Mb AMI BIOS with ACPI, SM BIOS 2.3.1, PnP
Graphics
- Integrated Mirage Graphics
- Shared Memory Max. 64MB
Audio
- AC97 CODEC
- 5.1 CH Audio
LAN
- 802.3u, 10/100 Ethernet LAN, WOL supported
- Supports PXE
Slots
- AGP 8X/4X 1.5V
- 2 x PCI slots, PCI 2.2
- 1 x AMR
Connector
- 2 x IDE ATA 133/100/66/33
- 1 x Floppy connector
- SIR/CIR 1/0
- CPU/Chassis FAN connectors
- 20 pin ATX power connector
- CD/AUX/ audio in
- Front panel audio connector
Rear Panel I/O
ASROCK I/O:
- 1 x Keyboard PS2
- 1 x Mouse PS2
- 4 x USB2.0 ports default on rear panel + 2 ports upgrade VIA® header
- 1 x Parallel
- 1 x Game/MIDI
- 1 x LAN RJ45
- Audio I/O Line In/Line Out/Mic.
- 1 x VGA
Unique Feature
Hybrid Booster:
- CPU Frequency Stepless control
- CPU Multiplier
- CPU Vcore adjustment
- ASRock U-COP
- Boot Failure Guard
Hardware Monitor
- CPU Temperature Sensing
- Motherboard Temperature Sensing
- CPU Fan Tachometer
- Chassis Fan Tachometer
- Voltage Monitoring: +12V, +5V, +3.3V, Vcore
Form Factor
- Micro ATX, 244mm x 198mm
OS
- Microsoft® Windows® 98SE/ME/2000/XP compliant
Lieferumfang
Das Mainboard inkl. Blende ohne weiteres Zubehör * gebraucht *
Abbildung ähnlich
