Asus P5KC Rev 1.03G Mainboard +Blende Sockel 775 Intel P35 DDR2 DDR3 PCIe* m966

Asus P5KC Rev 1.03G Mainboard + Blende Sockel 775 Intel P35 DDR2 oder DDR3 PCIe

Technische Daten

CPU

Intel® Socket 775 Core™2 Quad / Core™2 Extreme / Core™2 Duo / Pentium® Extreme / Pentium® D / Pentium® 4 / Celeron

Compatible with Intel® 05B/05A/06 processors

Support Intel next generation 45nm multi-core CPU (nach Bios Update!)

Chipsatz

Intel® P35 + Intel ICH9

Front Side Bus

1600/1333/1066/800 MHz

Memory

2 x DIMM, Max. 4 GB, DDR3 1333(O.C.)/1066/800 Non-ECC, Un-buffered Memory

Dual Channel memory architecture

Wahlweise nur DDR2 oder DDR3 seperat nutzbar! Nicht gleichzeitig belegbar!

4 x DIMM, max. 8GB, DDR2 1066*/800 / 667 MHz, non-ECC, un-buffered memory

Dual channel memory architecture

*The chipset officially supports the memory frequency up to DDR3 1066MHz/DDR2 800. Due to the tuning by ASUS exclusive technology, this motherboard natively supports up to DDR3 1333/DDR2 1066MHz. Please refer to the Website of Asus or user manual for Memory QVL

**When installing total memory of 4GB capacity or more, Windows 32-bit operation system may only recognize less than 3GB. Hence, a total installed memory of less than 3GB is recommended.

Expansion Slots

2 x PCIe x16 (blue @16x; black @ x4 or x1 mode)

1 x PCIe x1

3 x PCI

Supports CrossFire Technology

Storage

by Southbridge

4 x SATA 3 GB/s ports

by JMicron® JMB363 PATA and SATA controller

1 x UltraDMA 133/100/66 for up to 2 PATA devices

1 x External SATA 3.0 Gb/s ports

1 x SATA 3.0 Gb/s port (SATA On-the-Go)

Support RAID 0, 1, JBOD

LAN

PCIe 10/100/1000 Gigabit Lan controller

Audio

Realtek ALC 883 8-Channel High-Definition Audio CODEC

Coaxial / Optical S/PDIF out ports at back I/O

Support Jack-Sensing, Enumeration, Multi-streaming

USB

12 USB 2.0/1.1 ports (6 ports at mid-board, 6 ports at back panel)

IEEE 1394

VIA VT6308P controller supports 2 x 1394a ports (1 at midboard; 1 at back panel)

ASUS Unique Features

ASUS Quiet Thermal Solution       ASUS AI Gear 2; ASUS AI Nap; ASUS Fanless Design Heatsink solution; ASUS Fanless Design: Stack Cool 2; ASUS Q-Fan 2

ASUS Crystal Sound       ASUS Noise Filter

ASUS EZ DIY       ASUS Q-Connector; ASUS O.C. Profile; ASUS CrashFree BIOS 3; ASUS EZ Flash 2; ASUS AI Slot Detector

Other Features

ASUS MyLogo 2

Overclocking Features

Intelligent overclocking tools       ASUS AI Booster Utility; ASUS AI NOS (Non-delay Overclocking System)

Precision Tweaker       vDIMM: 8 -step DRAM voltage control; vCore: Adjustable CPU voltage at 0.0125V increment; vChipset 4-step voltage control

SFS (Stepless Frequency Selection)       FSB tuning from 200MHz up to 800MHz at 1MHz increment; Memory tuning from 667MHz up to 1333MHz; PCI Express frequency tuning from 100MHz up to 150MHz at 1MHz increment; Memory tunning from 800MHz up to 1333MHz for DDR3

Overclocking Protection       ASUS C.P.R.(CPU Parameter Recall)

Back Panel I/O Ports

1 x PS/2 Keyboard

1 x External SATA

1 x Optical SPDIF Out

1 x Coaxial SPDIF Out

1 x IEEE 1394a Firewire

1 x RJ45 Gigabit LAN

6 x USB 2.0/1.1

8-channel Audio I/O

Internal I/O Connectors

5 x SATA connectors

1 x IDE connector for up to 2 devices

1 x Floppy Disk Drive connector

1 x Front Panel Audio connector (AAFP)

1 x System Panel connector

3 x USB 2.0 connector supports additional 6 USB 2.0 ports

1 x IEEE1394a connector supports additional 1 IEEE1394 port

1 x CPU FAN connector (4-pin)

1 x Power FAN connector (3-pin)

2 x Chassis FAN connectors (3-pin)

1 x S/PDIF Out connector

1 x Chassis Intrusion connector

1 x CD/AUX Audio in connector

1 x Internal Speaker connector

24-pin ATX Power connector

4-pin ATX 12V Power connector

BIOS

8 Mb Flash ROM DMI 2.0

AMI BIOS, PnP, WfM2.0, SMBIOS v2.3, ACPI v2.0a

Manageability

WfM 2.0, DMI 2.0, WOL by PME, WOR by PME, PXE

Form Factor

ATX Form Factor; 12" x 9,6" ( 30.5 cm x 24.4 cm )

Lieferumfang

Das Mainboard inkl. Blende * ohne weiteres Zubehör * gebraucht *

Abbildung ähnlich
