Gigabyte GA-8I945PE REV 1.0 Mainboard + Blende So 775 Intel 945P Chipset m39

Gigabyte GA-8I945PE REV 1.0 Mainboard + Blende

Technische Daten:

CPU

  Supports Intel ® Pentium ® D / Pentium ® 4 LGA775 CPU

  Supports 1066/800/533MHz FSB

  L2 cache varies with CPU

  Chipset

  Northbridge: Intel ® 945P Express chipset

Southbridge: Intel ® ICH7

  Supported on the Win 2000/XP/MCE operating systems

  Memory

  4 DDRII DIMM memory slots (supports up to 4GB memory)

  Supports dual channel DDR II 667 (Note 2) /533/400 DIMM

  Supports 1.8V DDR II DIMM

  Slots

  1 PCI Express x 16 slot

  1 PCI Express x 1 slot

  2 PCI slots

  IDE Connections

  1 IDE connection (UDMA 33/ATA 66/ATA 100), allows connection of 2 IDE devices

  FDD Connections

  1 FDD connection, allows connection of 2 FDD devices

  Onboard SATA 3Gb/s

  4 SATA 3Gb/s connections

  Supported on the Win 2000/XP/MCE operating systems

  Peripherals

  1 parallel port supporting Normal/EPP/ECP mode

  1 COMA port

  8 USB 2.0/1.1 ports

  1 front audio connector

  Onboard LAN

  Onboard 82562 chip (10/100 Mbit)

  1 RJ 45 port

  Onboard Audio

  ALC880 CODEC

  Supports Jack Sensing function

  Supports 2 / 4 / 6 / 8 channel audio

  Supports Line In ; Line Out (Front Speaker Out) ; MIC ;

  Surround Speaker Out (Rear Speaker Out) ; Center/Subwoofer Speaker Out ;

  Side Speaker Out connection

  Supports SPDIF Out connection

  AUX_In

  (Note 1) Due to standard PC architecture, a certain amount of memory is reserved for system usage and therefore the actual memory size is less than the stated amount.

  For example, 4 GB of memory size will instead be shown as 3.xxGB memory during system startup.

  (Note 2) To use a DDRII 667 memory module on the motherboard, you must install an 800/1066MHz FSB processor .

  I/O Control

  IT8712

  Hardware Monitor

  System voltage detection

  CPU temperature detection

  CPU / System fan speed detection

  CPU warning temperature

  CPU / System fan failure warning

  CPU smart fan control

  BIOS

  Use of licensed AWARD BIOS

  Form Factor

Micro ATX form factor; 24.4 cm x 24.4cm

Lieferumfang

Das Mainboard inkl. Blende ohne weiteres Zubehör * gebraucht *

Abbildung ähnlich
