MSI MS-7318 Ver1.1 Medion MD 8818 8822 Mainboard +Blende Sockel 775 mBTX* m958

MSI MS-7318 Ver 1.1 Medion MD 8818 8822 Mainboard + Blende Sockel 775 DDR2 PCIe mBTX

Technische Daten

CPU

Supports Intel LGA775 Conroe E6300 / E6400 / E6700 / E6800, Prescott 500 Sequence, Cedar Mill, Smithfield and Celeron D processors (möglicherweise Bios Update notwendig!)

Chipset

VIA PT890CE Northbridge and VT8251L Southbridge Chipset

Main Memory

Supports Single Channel DDR2 533 (240pin / 1.8V)

2 x DDR2 DIMMs slots (2GB Max. memory size)

Slots

1 x PCI Express x16 slot

1 x PCI Express x1 slot

2 x PCI slots (1x PCI blau für Medion/Creatix Combo-Karten)

On-Board SATA

4 x SATA ports; Supports storage and data transfers at up to 150MB/s

Audio

8-channel Audio Chipset integrated by Realtek® ALC888

LAN

Supports 10/100 Fast Ethernet by Realtek 82001CL

IEEE1394

Chipset integrated by VT6308P with transfer rates up to 400Mbps

Internal I/O Connectors

1 x ATX 24-pin power connector

1 x ATX 4-pin 12V CPU power connector

1 x CPU connector (4-pin)

1 x System FAN connector (3-pin)

1 x Front Audio Panel connector

1 x Front Line connector

1 x Scart Output connector

1 x Front System Panel connector

1 x Clear CMOS jumper

1 x JSMI1 jumper

1 x Front LCD Panel connector

1 x Buzzer

1 x FWH/LPC Debugging connector

1 x IEEE1394 connector support additional 1 port

2 x USB 2.0 connectors support additional 4 ports

4 x Serial ATA connectors

1 x IDE connector for up to two devices

1 x Floppy/FDD connector

Back Panel I/O Ports

1 x Digital Audio IN SPDIF Coaxial

1 x Digital Audio IN SPDIF Optical

1 x Digital Audio OUT SPDIF Coaxial

1 x Digital Audio OUT SPDIF Optical

5 x Audio jacks (Front, Back surround, Center/Subwoofer, Side Surround, Line-IN)

1 x IEEE1394 Port

4 x USB 2.0 ports

1 x RJ45 LAN jack

1 x PS/2 Keyboard port

1 x PS/2 Mouse port

1 x Serial port (COM)

1 x Parallel port (LPT)

Dimension

ca. 26.7cm(L) x 26.5cm(W); M-BTX Form Factor

Lieferumfang

Das Mainboard inkl. Blende - ohne weiteres Zubehör * gebraucht *

Abbildung ähnlich
