CPU Prozessor AMD Athlon 64 3000+ ADA3000AEP4AR FSB1000 Sockel 754 *c148

General information

Type

CPU / Microprocessor

Market segment

Desktop

Family

AMD Athlon 64

Model number  ?

3000+

CPU part numbers

• ADA3000AEP4AR is an OEM/tray microprocessor
• ADA3000BOX is a boxed microprocessor

Stepping codes

AAARC   CAA2C   CAAPC   CAAZC

Frequency  ?

3000+ (rated)
2000 MHz (real)

Clock multiplier  ?

10

Package

754-pin lidded microPGA
1.57" x 1.57" (4 cm x 4 cm)

AMD Package number

27872

Socket

Socket 754

Architecture / Microarchitecture

Microarchitecture

K8

Processor core  ?

ClawHammer

Core stepping  ?

SH-CG

CPUID

F4A

Manufacturing process

0.13 micron silicon-on-insulator (SOI) technology

Data width

64 bit

The number of CPU cores

1

The number of threads

1

Floating Point Unit

Integrated

Level 1 cache size  ?

64 KB 2-way set associative instruction cache
64 KB 2-way set associative data cache

Level 2 cache size  ?

512 KB exclusive 16-way set associative cache

Physical memory

1 TB

Virtual memory

256 TB

Multiprocessing

Uniprocessor

Features

• MMX instructions
• Extensions to MMX
• 3DNow! technology
• Extensions to 3DNow!
• SSE / Streaming SIMD Extensions
• SSE2 / Streaming SIMD Extensions 2
• AMD64 / AMD 64-bit technology  ?
• EVP / Enhanced Virus Protection  ?

Low power features

• Halt state
• Stop Grant state  ?
• Cool'n'Quiet technology

Integrated peripherals / components

Integrated graphics

None

Memory controller

The number of controllers: 1
Memory channels: 1
Supported memory: DDR

Other peripherals

One 16-bit HyperTransport link with speeds up to 800 MHz

Electrical / Thermal parameters

V core  ?

1.5V

Maximum operating temperature  ?

70°C

Thermal Design Power  ?

89 Watt

Notes on AMD Athlon 64 3000+ (rev. CG, AR, L2 512KB)

• In the minimum performance state (P-state) the processor runs at 1000 MHz and 1.1 Volt core voltage. Thermal Design Power in the minimum P-state is 22 Watt
