CPU Prozessor AMD Athlon 64 3200+ ADA3200AEP5AP FSB800 1MB Sockel 754* c152

Technische Daten

Type

CPU / Microprocessor

Market segment

Desktop

Family

AMD Athlon 64

Model number

3200+

CPU part numbers

ADA3200AEP5AP is an OEM/tray microprocessor; ADA3200BOX is a boxed microprocessor

Stepping codes

CAAAC   CAAKC   CAAMC   CAAOC

Frequency

3200+ (rated); 2000 MHz (real)

Clock multiplier

10

Package

754-pin lidded microPGA; 1.57" x 1.57" (4 cm x 4 cm)

AMD Package number

27872

Socket

Socket 754

Introduction date

Sep 23, 2003

Price at introduction

$417

Architecture / Microarchitecture

Microarchitecture

K8

Processor core

ClawHammer

Core stepping

SH-C0

CPUID

F48

Manufacturing process

0.13 micron silicon-on-insulator (SOI) technology

Data width

64 bit

The number of CPU cores

1

The number of threads

1

Floating Point Unit

Integrated

Level 1 cache size

64 KB 2-way set associative instruction cache; 64 KB 2-way set associative data cache

Level 2 cache size

1 MB exclusive 16-way set associative cache

Physical memory

1 TB

Virtual memory

256 TB

Multiprocessing

Uniprocessor

Features

MMX instructions, Extensions to MMX, 3DNow! technology, Extensions to 3DNow!, SSE / Streaming SIMD Extensions, SSE2 / Streaming SIMD Extensions 2, AMD64 / AMD 64-bit technology, EVP / Enhanced Virus Protection

Low power features

Halt state, Stop Grant state, Cool'n'Quiet technology

Memory controller

The number of controllers: 1
Memory channels: 1
Supported memory: DDR

Other peripherals

One 16-bit HyperTransport link with speeds up to 800 MHz

Electrical / Thermal parameters

V core

1.5V

Maximum operating temperature

70°C

Thermal Design Power

89 Watt

Notes on AMD Athlon 64 3200+ (rev. C0)

In the minimum performance state (P-state) the processor runs at 800 MHz and 1.3 Volt core voltage. Thermal Design Power in the minimum P-state is 35 Watt
