CPU AMD Athlon64 X2 4600+ ADA4600DAA5BV Dual Core FSB1000 2x512K Sockel 939*c345

Technische Daten

Type

CPU / Microprocessor

Market segment

Desktop

Family

AMD Athlon 64 X2

Model number

4600+

CPU part numbers

ADA4600DAA5BV is an OEM/tray microprocessor; ADA4600BVBOX is a boxed microprocessor with fan and heatsink

Stepping codes

ADBHE   CDBHE   LDBFE   LDBHE

Frequency

4600+ (rated); 2400 MHz (real)

Clock multiplier

12

Package

939-pin lidded organic microPGA

Socket

Socket 939

Size

1.57" x 1.57" / 4cm x 4cm

Introduction date

May 31, 2005

Price at introduction

$803

Architecture / Microarchitecture

Microarchitecture

K8

Processor core

Manchester

Core stepping

E4

CPUID

20FB1

Manufacturing process

0.09 micron
150 million transistors

Data width

64 bit

The number of CPU cores

2

The number of threads

2

Floating Point Unit

Integrated

Level 1 cache size

2 x 64 KB 2-way set associative instruction caches
2 x 64 KB 2-way set associative data caches

Level 2 cache size

2 x 512 KB exclusive 16-way set associative caches

Physical memory

1 TB

Virtual memory

256 TB

Multiprocessing

Uniprocessor

Features

MMX instructions, Extensions to MMX, 3DNow! technology, Extensions to 3DNow!, SSE / Streaming SIMD Extensions, SSE2 / Streaming SIMD Extensions 2, SSE3 / Streaming SIMD Extensions 3, AMD64 / AMD 64-bit technology, EVP / Enhanced Virus Protection

Low power features

Halt state, Stop Grant state, Cool'n'Quiet technology

Memory controller

The number of controllers: 1
Memory channels: 2
Supported memory: DDR

Other peripherals

HyperTransport link

Electrical / Thermal parameters

V core

1.3V / 1.35V

Maximum operating temperature

49°C - 65°C

Thermal Design Power

110 Watt

Notes on AMD Athlon 64 X2 4600+ (Socket 939, rev. E4)

In the minimum performance state (P-state) the processor runs at 1000 MHz and 1.1 Volt core voltage. Thermal Design Power in the minimum P-state is 46.6 Watt
