Produktbeschreibung
CPU Prozessor AMD Athlon XP 2100+ AX2100DMT3C
FSB266 Sockel A 462 braun
Technische Daten | |
Type | CPU / Microprocessor |
Market segment | Desktop |
Family | AMD Athlon XP |
Model number | 2100+ |
CPU part number | AX2100DMT3C is an OEM/tray microprocessor |
Stepping codes | AGOIA AROIA |
Frequency | 2100+ (rated); 1733 MHz (real) |
Bus speed | 266 MHz |
Clock multiplier | 13 |
Package | 453-pin organic PGA; 1.95" x 1.95" (4.95 cm x 4.95 cm) |
AMD Package number | 27111 |
Socket | Socket A (Socket 462) |
Introduction date | 13-Mar-02 |
Price at introduction | $420 |
Architecture / Microarchitecture | |
Microarchitecture | K7 |
Processor core | Palomino (Model 6) |
Manufacturing process | 0.18 micron copper process |
Die | 129.26mm2 (total); 105.72mm2 (without L2 cache) |
Data width | 32 bit |
The number of CPU cores | 1 |
The number of threads | 1 |
Floating Point Unit | Integrated |
Level 1 cache size | 64 KB code; 64 KB data |
Level 2 cache size | Full-speed on-die 256 KB |
Multiprocessing | Uniprocessor |
Features | MMX instructions, Extensions to MMX, 3DNow! technology, Extensions to 3DNow!, SSE / Streaming SIMD Extensions |
Low power features | Halt state, Stop Grant states, Sleep state, Probe state |
Electrical / Thermal parameters | |
V core | 1.75V |
Minimum/Maximum operating temperature | 0°C - 90°C |
Minimum/Typical/Maximum power dissipation | 2 Watt (Stop Grant mode) / 64.3 Watt / 72 Watt |
Notes on AMD Athlon XP 2100+ (Palomino) | |
Actual bus frequency is 133 MHz. Because the processor uses Double Data Rate bus the effective bus speed is 266 MHz. | |
Lieferumfang
CPU - ohne weiteres Zubehör * gebraucht *
Abbildung ähnlich
Herstellerangabe / Produktsicherheit
Alle unsere hier angebotenen Produkte sind erstmalig vor dem 13.12.2024 in der EU in Verkehr gebracht worden und entsprechen den aktuellen Sicherheitsstandards.
Sie unterliegen nicht den neuen Anforderungen der GPSR.
