453-pin organic PGA 1.95" x 1.95" (4.95 cm x 4.95 cm)
AMD Package numbers
27493, 28103
Socket
Socket A (Socket 462)
Architecture / Microarchitecture
Microarchitecture
K7
Processor core ?
Barton (Model 10)
Manufacturing process
0.13 micron copper process
Data width
32 bit
The number of CPU cores
1
The number of threads
1
Floating Point Unit
Integrated
Level 1 cache size ?
64 KB code 64 KB data
Level 2 cache size ?
Full-speed exclusive on-die 512 KB
Multiprocessing
Uniprocessor
Features
MMX instructions
Extensions to MMX
3DNow! technology
Extensions to 3DNow!
SSE / Streaming SIMD Extensions
Low power features
Halt state
Stop Grant states
Sleep state ?
Probe state
Integrated peripherals / components
Integrated graphics
None
Electrical / Thermal parameters
V core ?
1.65V
Minimum/Maximum operating temperature ?
0°C - 85°C
Typical/Maximum power dissipation
53.7 Watt / 68.3 Watt
Notes on AMD Athlon XP 3000+ (400FSB)
Actual bus frequency is 200 MHz. Because the processor uses Double Data Rate bus the effective bus speed is 400 MHz.
Lieferumfang
CPU - ohne weiteres Zubehör * gebraucht *
Abbildung ähnlich
