CPU Prozessor AMD Duron 1300MHz DHD1300AMT1B Sockel A 462 FSB200 64KB* c36

Technische Daten

Type

CPU / Microprocessor

Market segment

Desktop

Family

AMD Duron

CPU part number

DHD1300AMT1B is an OEM/tray microprocessor

Stepping codes

AGOIA   AHLCA   AHLDA   AHSDA

Frequency

1300 MHz

Bus speed

200 MHz

Clock multiplier

13

Package

453-pin staggered ceramic PGA; 1.95" x 1.95" (4.95 cm x 4.95 cm)

AMD Package numbers

27067, 27100

Socket

Socket A (Socket 462)

Introduction date

21-Jan-02

Price at introduction

$118

Architecture / Microarchitecture

Microarchitecture

K7

Processor core

Morgan (Model 7)

CPUID

671

Manufacturing process

0.18 micron; 25.2 million transistors

Die

105.68mm2; 99.61mm2 (without L2 cache)

Data width

32 bit

The number of CPU cores

1

The number of threads

1

Floating Point Unit

Integrated

Level 1 cache size

64 KB 2-way set associative instruction cache; 64 KB 2-way set associative data cache

Level 2 cache size

On-die 64 KB 16-way set associative exclusive cache

Multiprocessing

Uniprocessor

Extensions and Technologies

MMX instructions; Extensions to MMX; 3DNow! technology; Extensions to 3DNow!; SSE / Streaming SIMD Extensions

Low power features

Halt state; Stop Grant states; Sleep state; Probe state

Integrated peripherals / components

Integrated graphics

None

Electrical / Thermal parameters

V core

1.75V

Minimum/Maximum operating temperature

0°C - 90°C

Minimum/Typical/Maximum power dissipation

2 Watt (Sleep state) / 55.2 Watt / 60 Watt

Notes on AMD Duron 1.3 GHz

Actual bus frequency is 100 MHz. Because the processor uses Double Data Rate bus the effective bus speed is 200 MHz.
