Produktbeschreibung
AMD Duron 1400MHz DHD1400DLV1C braun
General information | |
Type | CPU / Microprocessor |
Market segment | Desktop |
Family | AMD Duron |
CPU part number | DHD1400DLV1C is an OEM/tray microprocessor |
Stepping codes | MIRFA MIUGA MIUHB MIXIB |
Frequency ? | 1400 MHz |
Bus speed ? | 266 MHz |
Clock multiplier ? | 10.5 |
Package | 453-pin organic PGA |
AMD Package numbers | 27291, 27648 |
Socket | Socket A (Socket 462) |
Architecture / Microarchitecture | |
Microarchitecture | K7 |
Processor core ? | Applebred (Model 8) |
Manufacturing process | 0.13 micron |
Data width | 32 bit |
The number of CPU cores | 1 |
The number of threads | 1 |
Floating Point Unit | Integrated |
Level 1 cache size ? | 64 KB code |
Level 2 cache size ? | on-die 64 KB exclusive cache |
Multiprocessing | Uniprocessor |
Features | MMX instructions Extensions to MMX 3DNow! technology Extensions to 3DNow! SSE / Streaming SIMD Extensions |
Low power features | Halt state Stop Grant states Sleep state ? Probe state |
Integrated peripherals / components | |
Integrated graphics | None |
Electrical / Thermal parameters | |
V core ? | 1.5V |
Minimum/Maximum operating temperature ? | 0°C - 85°C |
Typical/Maximum power dissipation | 45.5 Watt / 57 Watt |
Notes on AMD Duron 1.4 GHz | |
Actual bus frequency is 133 MHz. Because the processor uses Double Data Rate bus the effective bus speed is 266 MHz. | |
Lieferumfang
CPU - ohne weiteres Zubehör * gebraucht *
Abbildung ähnlich
Herstellerangabe / Produktsicherheit
Alle unsere hier angebotenen Produkte sind erstmalig vor dem 13.12.2024 in der EU in Verkehr gebracht worden und entsprechen den aktuellen Sicherheitsstandards.
Sie unterliegen nicht den neuen Anforderungen der GPSR.
