Produktbeschreibung
CPU Prozessor AMD Duron 900MHz D900AUT1B
Sockel A 462 FSB200 64KB
Technische Daten | |
Type | CPU / Microprocessor |
Market segment | Desktop |
Family | AMD Duron |
CPU part number | D900AUT1B is an OEM/tray microprocessor |
Stepping codes | AKCA ANCA ANDA BNDA |
Frequency | 900 MHz |
Bus speed | 200 MHz |
Clock multiplier | 9 |
Package | 453-pin staggered ceramic PGA; 1.95" x 1.95" (4.95 cm x 4.95 cm) |
AMD Package number | 27016 |
Socket | Socket A (Socket 462) |
Introduction date | 2-Apr-01 |
Price at introduction | $129 |
Architecture / Microarchitecture | |
Microarchitecture | K7 |
Processor core | Spitfire (Model 3) |
CPUID | 631 |
Manufacturing process | 0.18 micron; 25 million transistors |
Data width | 32 bit |
The number of CPU cores | 1 |
The number of threads | 1 |
Floating Point Unit | Integrated |
Level 1 cache size | 64 KB code; 64 KB data |
Level 2 cache size | on-die 64 KB exclusive cache |
Multiprocessing | Uniprocessor |
Features | MMX instructions, Extensions to MMX, 3DNow! technology, Extensions to 3DNow! |
Low power features | Halt state, Stop Grant states, Sleep state, Probe state |
Electrical / Thermal parameters | |
V core | 1.6V ± 0.1V |
Minimum/Maximum operating temperature | 0°C - 90°C |
Typical/Maximum power dissipation | 35.4 Watt / 39.5 Watt |
Notes on AMD Duron 900 MHz | |
Actual bus frequency is 100 MHz. Because the processor uses Double Data Rate bus the effective bus speed is 200 MHz. | |
Lieferumfang
CPU - ohne weiteres Zubehör * gebraucht *
Abbildung ähnlich
Herstellerangabe / Produktsicherheit
Alle unsere hier angebotenen Produkte sind erstmalig vor dem 13.12.2024 in der EU in Verkehr gebracht worden und entsprechen den aktuellen Sicherheitsstandards.
Sie unterliegen nicht den neuen Anforderungen der GPSR.
