CPU Prozessor AMD Athlon 64 3500+ ADA3500IAA4CW FSB1000 512KB Sockel AM2* c75

Technische Daten

Type

CPU / Microprocessor

Market segment

Desktop

Family

AMD Athlon 64

Model number

3500+

CPU part numbers

ADA3500IAA4CW is an OEM/tray microprocessor; ADA3500CWBOX is a boxed microprocessor with fan and heatsink

Stepping codes

ACBXF   CCBIF   CCBYF   HFCHF   LDB4F   LDB5F   LDB8F   LDBDF   LDBIF   LEDBF   LFBAE   NDB5F   NDBDF

Frequency

3500+ (rated); 2200 MHz (real)

Bus speed

One 1000 MHz 16-bit HyperTransport link (2 GT/s)

Clock multiplier

11

Package

940-pin organic micro Pin Grid Array (micro-PGA)

Socket

Socket AM2

Introduction date

May 23, 2006

Architecture / Microarchitecture

Microarchitecture

K8

Processor core

Orleans

Core stepping

DH-F2

CPUID

50FF2

Manufacturing process

0.09 micron silicon-on-insulator (SOI) technology; 164 million transistors

Die

103.1mm2

Data width

64 bit

The number of CPU cores

1

The number of threads

1

Floating Point Unit

Integrated

Level 1 cache size

64 KB 2-way set associative instruction cache; 64 KB 2-way set associative data cache

Level 2 cache size

512 KB 16-way set associative exclusive cache

Physical memory

1 TB

Virtual memory

256 TB

Multiprocessing

Uniprocessor

Extensions and Technologies

MMX instructions; Extensions to MMX; 3DNow! technology; Extensions to 3DNow!; SSE / Streaming SIMD Extensions; SSE2 / Streaming SIMD Extensions 2; SSE3 / Streaming SIMD Extensions 3; AMD64 / AMD 64-bit technology; AMD-V / AMD Virtualization technology

Security Features

EVP / Enhanced Virus Protection

Low power features

Cool'n'Quiet technology; Halt state; Stop Grant state

Integrated peripherals / components

Integrated graphics

None

Memory controller

The number of controllers: 1
Memory channels (per controller): 2
Memory channels (total): 2
Supported memory: DDR2-800 [1]
Maximum memory bandwidth (GB/s): 12.8 [1]

Other peripherals

HyperTransport 2.0 technology (1 link)

Electrical / Thermal parameters

V core

1.25V / 1.35V / 1.4V

Maximum operating temperature

55°C - 69°C

Thermal Design Power

59 Watt

Notes on AMD Athlon 64 3500+ (rev. F2, 59W, CW)

In the minimum performance state (P-state) the processor runs at 1000 MHz and 1.1 Volt core voltage. Thermal Design Power in the minimum P-state is 28.7 Watt

According to 2006 roadmap the maximum supported memory is DDR2-667

[1] - Information is not confirmed
