CPU Prozessor AMD Athlon 64 X2 4800+ ADO4800IAA5DO FSB1000 Sockel AM2* c215

General information

Type

CPU / Microprocessor

Market segment

Desktop

Family

AMD Athlon 64 X2

Model number  ?

4800+

CPU part numbers

ADO4800IAA5DO is an OEM/tray microprocessor

ADO4800DOBOX is a boxed microprocessor with fan and heatsink

Stepping codes

AAA9G   CAA9G   CAAEG   CAAFG   CAAIG   CAAWG   NAA9G   NAAFG   NAAIG   NAAWG   NAAZG

Frequency  ?

4800+ (rated)
2500 MHz (real)

Bus speed  ?

One 1000 MHz 16-bit HyperTransport link (2 GT/s)

Clock multiplier  ?

12.5

Package

940-pin organic microPGA

Socket

Socket AM2

Architecture / Microarchitecture

Microarchitecture

K8

Platform

Cartwheel

Processor core  ?

Brisbane

Core stepping  ?

G2

Manufacturing process

0.065 micron silicon-on-insulator (SOI) technology
221 million transistors

Data width

64 bit

The number of CPU cores

2

The number of threads

2

Floating Point Unit

Integrated

Level 1 cache size  ?

2 x 64 KB 2-way set associative instruction caches
2 x 64 KB 2-way set associative data caches

Level 2 cache size  ?

2 x 512 KB exclusive 16-way set associative caches

Physical memory

1 TB

Virtual memory

256 TB

Multiprocessing

Uniprocessor

Features

MMX instructions

Extensions to MMX

3DNow! technology

Extensions to 3DNow!

SSE / Streaming SIMD Extensions

SSE2 / Streaming SIMD Extensions 2

SSE3 / Streaming SIMD Extensions 3

AMD64 / AMD 64-bit technology  ?

EVP / Enhanced Virus Protection  ?

AMD-V / AMD Virtualization technology

Low power features

Cool'n'Quiet technology

Halt state

Stop Grant state  ?

Integrated peripherals / components

Integrated graphics

None

Memory controller

The number of controllers: 1
Memory channels: 2
Supported memory: DDR2-800
Maximum memory bandwidth (GB/s): 12.8

Other peripherals

HyperTransport 2.0 technology

Electrical / Thermal parameters

V core  ?

1.325V / 1.35V / 1.375V

Maximum operating temperature  ?

55°C - 68°C

Thermal Design Power  ?

65 Watt
