Products description
Asus A7V266-MX Mainboard + Blende
Technische Daten:
CPU
Socket A for AMD Athlon™ XP/Athlon™/Duron processors
Chipset
VIA KM266
VIA VT8235 CE
Front Side Bus (FSB)
266/200 MHz
Memory
2 x 184-pin DDR DIMM sockets support up to maximum 2GB
unbuffered PC2100/1600 non-ECC DDR SDRAM memory.
Expansion slots
3 x PCI
1 x AGP 4X (1.5V only)
IDE
2 x UltraDMA133/100/66
Graphics
Integrated VIA UniChrome™ Graphics
Audio
AD1980 6-channel AUDIO CODEC
S/PDIF out interface
LAN
VIA VT6103 10/100 Mbps Ethernet PHY
Hardware monitoring
Super I/O integrated monitoring of CPU/chassis fan and MB/CPU temperature
Rear panel I/O ports
1 x Parallel
1 x Serial (COM1)
1 x PS/2 keyboard
1 x PS/2 mouse
1 x RJ45
1 x Audio I/O
1 x VGA
4 x USB 2.0
Internal connectors
1 x USB connector supports additional 2 USB 2.0 ports
CPU/chassis FAN connectors
Chassis intrusion connector
20-pin ATX power connector
CD / AUX connectors
S/PDIF out connector
GAME/MIDI connector
Front panel audio connector
BIOS features
2Mb Flash ROM, Award BIOS, ACPI, DMI2.0, WfM 2.0,
SMBIOS 2.3, PnP features, TCAV, ASUS EZ Flash,
CrashFree BIOS, ASUS C.O.P. (CPU Overheating
Protection)
Industry standard
PCI 2.2, USB 2.0
Manageability
WfM 2.0, DMI 2.0, WOL/WOR by PME, chassis intrusion
Form factor
Micro-ATX form factor: 9.6 in x 9.6 in
Lieferumfang
Das Mainboard inkl. Blende ohne weiteres Zubehör * gebraucht *
Abbildung ähnlich
