MSI Z68A-GD65 (G3) MS-7681 Ver:4.0 Mainboard + Blende Intel Z68 Sockel 1155 DDR3 HDMI
Technische Daten
CPU
Supports Intel® Sandy Bridge processors in LGA1155 package.
Please refer to CPU Support for compatible CPU; the above description is for reference only.
Chipset
Intel® Z68 (B3) Chipset
Main Memory
Supports four unbuffered DIMM of 1.5 Volt DDR3 1066/1333/1600*/2133*(OC) DRAM, 32GB Max
Supports 1GB/ 2GB/ 4GB/ 8GB DRAM size
Supports Dual channel mode
Slots
2 x PCI Express gen3 x16 slots
3 x PCIE x1 slots
2 x 32-bit v2.3 master PCI bus slots (Support 3.3v/5v PCI bus interface)
On-Board SATA
SATAII controller integrated in Intel® Z68 (B3) chipset
- Up to 3Gb/s transfer speed
- Supports four SATAII ports (SATA3~6) by Z68 (B3) PCH
SATAIII controller integrated in Intel® Z68 (B3) chipset
- Up to 6Gb/s transfer speed
- Supports two SATAIII ports (SATA1~2) by Z68 (B3) PCH
- SATA1~6 ports support RAID 0/1/5/10 mode by Intel Z68 (B3) PCH
SATAIII controller integrated in Marvell® 88SE9128 chipset
- Supports two SATA 6Gb/s ports
USB 3.0
1 x USB 3.0 internal connector by NEC® D720200
2 x USB 3.0 rear I/O ports by NEC® D720200
Audio
Chipset integrated by Realtek® ALC892
- Flexible 8-channel audio with jack sensing
- Compliant with Azalia 1.0 Spec
- Meet Microsoft Vista Premium spec
LAN
Supports one PCI Express LAN 10/100/1000 Fast Ethernet by Realtek 8111E.
Internal I/O Connectors
1 x ATX 24-Pin power connector
1 x 8-pin ATX 12V power connector
1 x 4-pin CPU FAN connector
1 x 4-pin System FAN connector
3 x 3-pin System FAN connectors
1 x COM1 connector
1 x Front panel audio connector
1 x JFP1 Front panel connector
1 x JFP2 Front panel connector
1 x JSPI1 Front panel connector
1 x Chassis intrusion connector
3 x USB 2.0 connectors
1 x USB 3.0 connector
4 x Serial ATAII connectors
4 x Serial ATAIII connectors
1 x Clear CMOS jumper
1 x SPDIF-out connector
1 x TPM module connector
1 x DLED3 connector
1 x Voltage Check Point FV1
1 x Power button
1 x Reset button
1 x OC Genie button
Back Panel I/O Ports
1 x PS/2 Mouse/Keyboard port
1 x Coaxial SPDIF port
1 x Optical SPDIF port
1 x Clear CMOS button
1 x RJ45 LAN Jack
4 x USB 2.0 ports
2 x USB 3.0 ports
1 x Graphics Card port
1 x DVI-D port
1 x HDMI port
1 x 6 in 1 audio jack
MSI Reminds You...
HDMI, DVI-D & Graphics Card ports can only work with CPUs with GPUs core inside.
BIOS
The motherboard BIOS provides "Plug & Play" BIOS which detects the peripheral devices and expansion cards of the board automatically.
The motherboard provides a Desktop Management Interface(DMI) function which records your motherboard specifications.
Dimension & Mounting
30.5cm(L) x 24.5cm(W) ATX Form Factor; 9 mounting holes
Lieferumfang
Das Mainboard inkl. Blende und Handbuch * ohne weiteres Zubehör * gebraucht *
Abbildung ähnlich
