MSI 915P Neo2 MS-7028 Ver. 10A Sockel 775 Mainboar

Products description

MSI 915P Neo2 MS-7028 Ver. 10A Sockel 775

Mainboard + Blende

Technische Daten:

CPU
•Supports Intel Pentium 4 Prescott processors in LGA 775 (Socket T) package
•Supports Pentium 4 3XX, 5XX and 7XX Processor or higher speed
•Supports Intel Hyper-Threading (HT) Technology

Chipset
Intel Grantsdale 915P Chipset
•Supports FSB 800MHz
•Support Dual channel DDR2 533+/533/400 memory interface upto 4GB
•Support PCI Express 16X interface

Intel ICH6R Chipset
•Integrated Hi-Speed USB 2.0 controller, 480Mb/sec, 8 ports
•4 Serial ATA/150 ports support RAID (0,1) and Matrix RAID
•1 channel Ultra ATA 100 bus Master IDE controller
•PCI Master v 2.3, I/O ACPI 2.0 Compliant
•Integrated AHCI controller

FSB
•Support 800+/800MHz

Main Memory
•Supports 4 unbuffered DIMM of 1.8 Volt DDR2 SDRAM
•Supports up to 4GB memory size
•Support Dual Channel DDR2 533/400MHz and up(*DDR2 Memory Modules are not the same as DDR Memory Module, please check with your memory vendor for more information)

Slots
•One PCI Express 16X slot
•Two PCI Express 1X slot
•Three PCI 2.2 32-bit Master PCI Bus slots. (support 3.3v/5v PCI bus interface)

On-Board IDE
One Ultra DMA 66/100 IDE controller integrated in ICH6R
•Supports PIO, Bus Master operation modes
•Can connect up to 2 Ultra ATA drives

Serial ATA 150 controller integrated in ICH6R
•Up to 150MB/s transfer speed
•Can connect up to 4 Serial ATA drives
•Supports ACHI controller with SATA RAID (0,1) and Matrix RAID
•Supports SATA hot plug

VIA 6410 IDE RAID Controller
•Integrate two Ultra DMA 66/100/133 IDE controllers
•Support RAID (0,1 and 0+1)
•Connect upto 4 Ultra ATA 133 devicesOn-Board Peripherals
•1 floppy port supports 1 FDD with 360K, 720K, 1.2M, 1.44M and 2.88Mbytes•1 Serial port (COM A)
•1 parallel port supports SPP/EPP/ECP mode
•8 USB 2.0 ports (Rear x 4/** Front x 4)(** Front USB ports are supported by pin-out)
•1 Line-In/Line-Out/Mic-In/RS Out/CS Out/SPDIF Out-Optica/Coaxial Audio port
•2 PS/2 connectors
•1 LAN RJ45 connector
•1 IEEE 1394

Audio
8 Channel Azalia controller integrated in Intel ICH6R Chipset
•8-channel audio codec Realtek ALC861
•Compliance with Azalia 1.X spec
•Support Multi-Streaming function
•Support Universal Audio Jack (only Front Audio Jack)

LAN
Broadcom DBM5751 PCI-Express Gb LAN Controller
•PCI Express bus Spec 1.a compliant
•PCI Express 1X interface with 2.5Gb/s bandwidth
•10/100/1000 IEEE 802.3 compliant

BIOS
•The mainboard BIOS provides "Plug & Play" BIOS which detects the peripheral devices and expansion cards of the board automatically.
•The mainboard provides a Desktop Management Interface(DMI) function which records your mainboard specifications.

Dimensions
30.5cm(L) x 24.5cm(W) ATX Form Factor

Mounting
9 mounting holes
