CPU Prozessor AMD Athlon 64 X2 4200+ ADA4200DAA5CD

Products description

AMD Athlon 64 X2 4200+ ADA4200DAA5CD

General information
Type	CPU / Microprocessor
Market segment	Desktop
Family	AMD Athlon 64 X2
Model number ?	4200+
CPU part numbers	ADA4200DAA5CD is an OEM/tray microprocessor ADA4200CDBOX is a boxed microprocessor with fan and heatsink
Stepping codes	ACBWE CCBWE LCB9E LCBIE LCBKE LCBQE
Frequency ?	4200+ (rated) 2200 MHz (real)
Bus speed ?	One 1000 MHz 16-bit HyperTransport link (2GT/s)
Clock multiplier ?	11
Package	939-pin lidded organic microPGA
Socket	Socket 939
Size	1.57" x 1.57" / 4cm x 4cm
Introduction date	May 5, 2005
Architecture / Microarchitecture
Microarchitecture	K8
Processor core ?	Toledo
Core stepping ?	E6
Manufacturing process	0.09 micron 150 million transistors
Data width	64 bit
The number of CPU cores	2
The number of threads	2
Floating Point Unit	Integrated
Level 1 cache size ?	2 x 64 KB 2-way set associative instruction caches 2 x 64 KB 2-way set associative data caches
Level 2 cache size ?	2 x 512 KB exclusive 16-way set associative caches
Physical memory	1 TB
Virtual memory	256 TB
Multiprocessing	Uniprocessor
Features	MMX instructions 3DNow! technology SSE / Streaming SIMD Extensions SSE2 / Streaming SIMD Extensions 2 SSE3 / Streaming SIMD Extensions 3 AMD64 / AMD 64-bit technology ? EVP / Enhanced Virus Protection ?
Low power features	Halt state Stop Grant state ? Cool'n'Quiet technology
Integrated peripherals / components
Integrated graphics	None
Memory controller	The number of controllers: 1 Memory channels: 2 Supported memory: DDR-400 Maximum memory bandwidth (GB/s): 6.4
Other peripherals	HyperTransport link
Electrical / Thermal parameters
V core ?	1.3V / 1.35V
Maximum operating temperature ?	49°C - 71°C
Thermal Design Power ?	89 Watt
