Products description
CPU AMD Athlon64 X2 5600+ ADA5600IAA6CZ
Dual Core FSB1000 2x1MB Sockel AM2
Technische Daten | |
Type | CPU / Microprocessor |
Market segment | Desktop |
Family | AMD Athlon 64 X2 |
Model number | 5600+ |
CPU part numbers | ADA5600IAA6CZ is an OEM/tray microprocessor; ADA5600CZBOX is a boxed microprocessor with fan and heatsink |
Stepping codes | ACB9F CCB6F CCB8F CCBVF |
Frequency | 5600+ (rated) ; 2800 MHz (real) |
Bus speed | One 1000 MHz 16-bit HyperTransport link (2GT/s) |
Clock multiplier | 14 |
Package | 940-pin organic micro Pin Grid Array (micro-PGA) |
Socket | Socket AM2 |
End-of-Life date | Last order date is end of 1st quarter 2008 |
Architecture / Microarchitecture | |
Microarchitecture | K8 |
Processor core | Windsor |
Core stepping | JH-F3 |
CPUID | 40F33 |
Manufacturing process | 0.09 micron silicon-on-insulator (SOI) technology; 243 million transistors |
Data width | 64 bit |
The number of CPU cores | 2 |
The number of threads | 2 |
Floating Point Unit | Integrated |
Level 1 cache size | 2 x 64 KB 2-way set associative instruction caches; 2 x 64 KB 2-way set associative data caches |
Level 2 cache size | 2 x 1 MB 16-way set associative exclusive caches |
Physical memory | 1 TB |
Virtual memory | 256 TB |
Multiprocessing | Uniprocessor |
Extensions and Technologies | MMX instructions; Extensions to MMX; 3DNow! technology; Extensions to 3DNow! ; SSE / Streaming SIMD Extensions; SSE2 / Streaming SIMD Extensions 2; SSE3 / Streaming SIMD Extensions 3; AMD64 / AMD 64-bit technology; EVP / Enhanced Virus Protection; AMD-V / AMD Virtualization technology |
Low power features | Cool'n'Quiet technology; Halt state; Stop Grant state |
Memory controller | The number of controllers: 1 |
Other peripherals | HyperTransport 2.0 technology (1 link) |
Electrical / Thermal parameters | |
V core | 1.3V / 1.35V |
Maximum operating temperature | 55°C - 70°C |
Thermal Design Power | 89 Watt |
Notes on AMD Athlon 64 X2 5600+ (2.8 GHz, 89W) | |
In the minimum performance state (P-state) the processor runs at 1000 MHz and 1.1 Volt core voltage. Thermal Design Power in the minimum P-state is 29.2 Watt | |
Lieferumfang
CPU - ohne weiteres Zubehör * gebraucht *
Abbildung ähnlich
