Products description
CPU Prozessor AMD Athlon 64 3500+ ADH3500IAA4DE FSB1000 512KB Sockel AM2
Technische Daten | |
Type | CPU / Microprocessor |
Market segment | Desktop |
Family | AMD Athlon 64 |
Model number | 3500+ |
CPU part numbers | ADH3500IAA4DE is an OEM/tray microprocessor; ADH3500DEBOX is a boxed microprocessor with fan and heatsink |
Stepping code | CAALG |
Frequency | 3500+ (rated); 2200 MHz (real) |
Bus speed | One 1000 MHz 16-bit HyperTransport link (2 GT/s) |
Clock multiplier | 11 |
Package | 940-pin organic micro Pin Grid Array (micro-PGA) |
Socket | Socket AM2 |
Introduction date | Feb 20, 2007 |
Price at introduction | $88 |
Architecture / Microarchitecture | |
Microarchitecture | K8 |
Processor core | Lima |
Core stepping | DH-G1 |
CPUID | 70FF1 |
Manufacturing process | 0.065 micron silicon-on-insulator (SOI) technology; 122 million transistors |
Die | 77.2mm2 |
Data width | 64 bit |
The number of CPU cores | 1 |
The number of threads | 1 |
Floating Point Unit | Integrated |
Level 1 cache size | 64 KB 2-way set associative instruction cache; 64 KB 2-way set associative data cache |
Level 2 cache size | 512 KB 16-way set associative exclusive cache |
Physical memory | 1 TB |
Virtual memory | 256 TB |
Multiprocessing | Uniprocessor |
Extensions and Technologies | MMX instructions; Extensions to MMX; 3DNow! technology; Extensions to 3DNow!; SSE / Streaming SIMD Extensions; SSE2 / Streaming SIMD Extensions 2; SSE3 / Streaming SIMD Extensions 3; AMD64 / AMD 64-bit technology; EVP / Enhanced Virus Protection; AMD-V / AMD Virtualization technology |
Low power features | Cool'n'Quiet technology; Halt state; Stop Grant state |
Integrated peripherals / components | |
Integrated graphics | None |
Memory controller | The number of controllers: 1 |
Other peripherals | HyperTransport 2.0 technology |
Electrical / Thermal parameters | |
V core | 1.25V / 1.3V / 1.35V |
Maximum operating temperature ? | 55°C - 65°C |
Thermal Design Power | 45 Watt |
Notes on AMD Athlon 64 3500+ (45W) | |
In the minimum performance state (P-state) the processor runs at 1000 MHz and 1.1 Volt core voltage. Thermal Design Power in the minimum P-state is 22.1 Watt | |
Lieferumfang
CPU - ohne weiteres Zubehör * gebraucht *
Abbildung ähnlich
