Products description
CPU Prozessor AMD Phenom II X4 840 HDX840WFK42GM 4x3.2GHz Sockel AM3 AM2+
Technische Daten | |
Type | CPU / Microprocessor |
Market segment | Desktop |
Family | AMD Phenom II X4 |
Model number | 840 |
CPU part numbers | HDX840WFK42GM is an OEM/tray microprocessor; HDX840WFGMBOX is a boxed microprocessor with fan and heatsink |
Stepping codes | AADIC AD NADIC AD |
Frequency | 3200 MHz |
Bus speed | 667 MHz Memory controller; One 2000 MHz 16-bit HyperTransport link (4 GT/s) |
Clock multiplier | 16 |
Package | 938-pin organic micro-PGA |
Sockets | Socket AM2+; Socket AM3 |
Weight | 1.4oz / 39.2g (CPU); 12.5oz / 353.6g (box) |
Fan/heatsink | DK8-7G52C-A1-GP |
Introduction date | Jan 4, 2011 |
Architecture / Microarchitecture | |
Microarchitecture | K10 |
Platform | Dragon |
Processor core | Propus |
Core stepping | BL-C3 |
CPUID | 100F43 |
Manufacturing process | 0.045 micron silicon-on-insulator (SOI) technology |
Die | 258mm2 |
Data width | 64 bit |
The number of CPU cores | 4 |
The number of threads | 4 |
Floating Point Unit | Integrated |
Level 1 cache size | 4 x 64 KB 2-way set associative instruction caches; 4 x 64 KB 2-way set associative data caches |
Level 2 cache size | 4 x 512 KB 16-way set associative exclusive caches |
Level 3 cache size | None |
Cache latency | 3 (L1 cache) |
Virtual memory | 256 TB |
Multiprocessing | Uniprocessor |
Extensions and Technologies | MMX instructions; Extensions to MMX; 3DNow! technology; Extensions to 3DNow!; SSE / Streaming SIMD Extensions; SSE2 / Streaming SIMD Extensions 2; SSE3 / Streaming SIMD Extensions 3; SSE4a; AMD64 / AMD 64-bit technology; AMD-V / AMD Virtualization technology |
Security Features | EVP / Enhanced Virus Protection |
Low power features | Cool'n'Quiet 3.0; CoolCore Technology; Dual Dynamic Power Management; Core C1 and C1E states; Package S0, S1, S3, S4 and S5 states |
Integrated peripherals / components | |
Integrated graphics | None |
Memory controller | The number of controllers: 1 |
Other peripherals | HyperTransport 3 technology |
Electrical / Thermal parameters | |
V core | 0.85V - 1.4V |
Maximum operating temperature | 71°C |
Thermal Design Power | 95 Watt |
Lieferumfang
CPU - ohne weiteres Zubehör * gebraucht *
Abbildung ähnlich
